Greadon offers a comprehensive range of angular contact ball bearings, designed to meet the evolving needs of equipment manufacturers across a wide range of industries.
The inner and outer ring raceways of angular contact ball bearings are offset relative to the bearing axis, forming a contact angle. Common contact angles include 15°, 25°, and 40°. This design enables the bearings to accommodate combined radial loads and unidirectional axial loads. When radial loads are high, an axial load component is generated, which is why angular contact ball bearings are typically used in matched pairs or in multi-bearing arrangements to ensure stable and reliable performance.
Parameters
If you are unsure how to choose, please contact us immediately. We offer free optimal solutions for you.
| Model |
d (mm) |
D (mm) |
B (mm) |
Model |
d (mm) |
D (mm) |
B (mm) |
| 7007 |
35 |
62 |
14 |
7206 |
30 |
62 |
16 |
| 7008 |
40 |
68 |
15 |
7207 |
35 |
72 |
17 |
| 7009 |
45 |
75 |
16 |
7208 |
40 |
80 |
18 |
| 7010 |
50 |
80 |
16 |
7209 |
45 |
85 |
19 |
| 7011 |
55 |
90 |
18 |
7210 |
50 |
90 |
20 |
| 7012 |
60 |
95 |
18 |
7211 |
55 |
100 |
21 |
| 7013 |
65 |
100 |
18 |
7212 |
60 |
110 |
22 |
| 7014 |
70 |
110 |
20 |
7213 |
65 |
120 |
23 |
| 7015 |
75 |
115 |
20 |
7214 |
70 |
125 |
24 |
| 7016 |
80 |
125 |
22 |
7215 |
75 |
130 |
25 |
Contact Angle:Non-separable design with different contact angles of 15 degrees, 25 degrees, and 40 degrees. The larger the contact angle, the greater the axial load the bearing can withstand.
High Precision:Suitable for high-precision applications requiring accurate positioning and stable operation.
High Speed:With low friction, it is suitable for high-speed operation, commonly used in high-speed motors and turbine machinery.
Unidirectional Axial Load:Can only withstand unidirectional axial loads, typically requiring pairing with another bearing to handle the reverse axial load.
Contact Angle:Non-separable design with different contact angles of 15 degrees, 25 degrees, and 40 degrees. The larger the contact angle, the greater the axial load the bearing can withstand.
High Precision:Suitable for high-precision applications requiring accurate positioning and stable operation.
High Speed:With low friction, it is suitable for high-speed operation, commonly used in high-speed motors and turbine machinery.
Unidirectional Axial Load:Can only withstand unidirectional axial loads, typically requiring pairing with another bearing to handle the reverse axial load.
